14 port USB-C Hub DS-90 (CNS-HDS90)

Product features

  • 1*USB-A 3.2 Gen 2 10 Gbps;
  • 1*USB-A 3.0 5 Gbps;
  • 1*USB-A 2.0 480 Mbps;
  • 1*USB-С 3.2 Gen 2 10 Gbps;
  • Ethernet 1000 Mbps;

14 port USB-C Hub DS-90

If your laptop is equipped with USB type-C, this universal docking station CNS-HDS90, which is the 3rd generation of the popular model, will improve its connectivity features with 14 built-in ports to the maximum. Using Display Port (4Kx60Hz) and VGA, you can connect your laptop to four monitors simultaneously. The up to 100W USB-C PD charging port allows you to charge your connected device at optimal speed.  Also, the USB hub Canyon HDS90 has built-in 3.5mm audio jack for headphones/microphone, SD and TF card reader, Ethernet for flawless internet connection and USB-С 3.2 Gen 2 for fast data transferring. The Hub CNS-HDS90 for 14 ports will make your workspace look stylish and modern.

Characteristics

TECHNICAL SPECIFICATIONS

  • Interface USB-C
  • Article CNS-HDS90
  • Ports VGA, USB, Gigabit Ethernet, Audio-In, HDMI, DisplayPort
  • Cable length 0.2 m
  • Housing materials Aluminum
  • Compatibility Devices with Windows 7+, MacOS 10+, Chromecast, Google Media Player
  • Charging port USB-C PD, max. 100 W
  • Connection method “Plug and Play”, “Hot Swap” mode
  • Gigabit Ethernet Network support 10/100/1000 Mbps
  • Supports Secure DigitalTM v1.0 / v1.1 / v2.0 / SDHC / SDXC (до 2TB) Secure DigitalTM v3.01 UHS-I (Ultra High Speed): SDR12 / SDR25 / SDR50 / DDR50 / SDR104

Interfaces

  • USB 3.2 х1 USB-A Gen 2 10 Gbps
    х1 USB-С Gen 2 10 Gbps
  • DisplayPort 1
  • Audio Interface х1 3.5-mm minijack
  • HDMI х1 HDMI (Type A), 4K*60 Hz
  • LAN х1 RJ-45
  • USB 3.0 х1 USB-A 5 Gbps
  • USB 2.0 х1 USB 2.0 (Type A), transfer rate max. 480 Mbps
  • VGA х1 15-pin D-sub, 1080P*60 Hz

Warranty

  • Warranty Available
  • Warranty Term 24 months
  • Warranty Validation Criteria Serial Number
